Product Details:
Payment & Shipping Terms:
|
| Product Name: | Hydraulic Crane Winch | Material: | Alloy Steel |
|---|---|---|---|
| Lifting Speed: | 0-60m/min | Produce Equipment: | Hydraulic |
| Rope Capacity: | 100-2000M | Application: | Lifting And Pulling Equipmernt |
| Brake: | Band Brake | Pulling Force: | 8.5Ton |
| High Light: | high speed hydraulic hoist and winch,diesel hydraulic hoist and winch,8.5 ton hydraulic crane winch |
||
The working principle of hydraulic transmission is to use the pressure energy of the liquid to transfer power, and the pressure energy of the liquid is converted into mechanical energy to drive the movement of the working parts. The hydraulic system must control and adjust the oil pressure, flow rate and direction to meet the requirements of force, speed and direction of the working parts.
| color | yellow /black /gray/as customes |
| size | 35*35*20 |
| Pull | 8/10/15/20 |
| layer | 1-7 |
| Wire rope capacity | 17-230 |
| Hydraulic motor | As customes |
| Planetary reduction ratio | I=5.23 |
| L/min |
As customes |
Hydraulic winch is mainly rated load larger winch, under normal circumstances more than 10T to 5000T winch design hydraulic winch.
Product Outline Drawing
|
Model |
Pull force (KN) |
Rope speed (m/min) |
Drum bottom Diameter (mm) |
Difference of working pressures (Mpa) |
Rope capacity (mm) |
Diameter of steel rope (mm) |
Model of hydraulic motor |
|
LBSW-DN10-10-00 |
10 | 0-40 | 250 | 13 | 100 | 10 | C2.5-5.5 |
| LBSW-DN12-18-00 | 12 | 0-40 | 250 | 12.5 | 100 | 12 | C2.5-5.5 |
| LBSW-DN14-20-00 | 20 | 0-35 | 300 | 12 | 100 | 14 | C2.5-5.5 |
| LBSW-DN15-30-00 | 30 | 0-30 | 350 | 14 | 100 | 15 | C3-5.5 |
| LBSW-DN22-65-00 | 65 | 0-35 | 550 | 15 | 200 | 22 | C5-5 |
| LBSW-DN24-80-00 | 80 | 0-30 | 600 | 16 | 200 | 24 | C5-5.5 |
| LBSW-DN30-120-00 | 120 | 0-30 | 750 | 16 | 200 | 30 | C7-5.5 |
| LBSW-DN38-180-00 | 180 | 0-30 | 860 | 16 | 200 | 38 |
C7-5.5
|
Asia / Australasia /Central / South America / Eastern Europe / North America / Western Europe
Q1.Are you a factory or a trading company? What can you provide?
We are a factory locates in industrial belt of Shijiazhuang City,our main products are hydraulic orbit motors, hydraulic winches, hydraulic brakes, hydraulic stee hole punchers, hydraulic steerings, etc.
Q2. I want to buy your product, how can I pay?
We support T/T, Paypal, Western Union, also you can pay through Alibaba trade assurance.
Q3.How about the warranty?
We promise to supply high quality products and professional after-sales service. We can supply technical support as long as you need,beyond that, we also offer six months of warranty.
Q4.If we don't find what we want on your website, what should we do?
You can start a conversation to us or send us email about the descriptions and pictures of the products you need, We will check if we can supply.
Q5.Can we buy 1pc of each item for quality testing?
Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
