LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch

LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch
LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch

Large Image :  LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: LBSD Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD, EUR, RMB / Negotiable
Packaging Details: Export standard wooden case
Delivery Time: General order 20-40 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 Pieces Per Month
Detailed Product Description
Name: Rope Winch Steel LBS Grooved Drum Application: Hoisting Winch
Material: Steel Q355D Rope Capacity: 300M
Rope Groove Type: Lebus Grooves Warranty: 1Year
Rated Speed: As Per Customers Requirement Weight: 1800kgs
Color: Gray Or As Your Demand Rope Diameter: 20mm
Highlight:

350mm rope winding drum

,

LBS Grooved winding drum

,

LBS Grooved cable winding drum

Professiona Machinery Manufacturing Wire Rope Winch Steel LBS Grooved Drum



Product Introduction

The LBS grooved winch drum is designed and produced specifically to meet the application for which is used. According to the rope’s diameter,length and construction type,we can confirm groove pattern.

Product information

Product name Professiona Machinery Manufacturing Wire Rope Winch Steel LBS Grooved Drum
Drum Quantity Single Or Double
Drum Design LBS Groove Or Spiral Groove
Material Carbon Stainless And Alloy Steels
Size Customization
Application Range Construction Mining Terminal operation
Power Source Electric and hydraulic
Rope Capacity 100~300M


The Characteristics Of The Grooves

1. It has specifically groove to make wire rope spooling orderly and uniform strength on every layer.

2. It can be calculated the exact forces that the rope imposed on the drum.

3. The spooling is totally under control,which prevents lower layers being crushed or pinched by upper layers

4. With the groove,the continuous groove in the drum is parallel to the flange except for two crossover points on each Revelution where the groove moves across the drum half a pitch to give a pull pitch of movement for each pitch.

The characteristics of LBS drum:

We adopts LBS groove,which can make the wire rope steady spooling from the first layer to second layer. In this process,it can lower the damage and increase service life of wire rope. At the same time,LBS groove can make wire rope spooling more smooth and uniform distribution of load between each layer.



Technical parameter:
Pull force(Kn) number of layers drum capacity drum diameter rotation direction
10 2 30m 350mm left or right
30 3 35m 500mm left or right
50 3 50m 700mm left or right
80 4 75m 800mm left or right
150 5 80m 800mm left or right



Product application:

As LBSD series winch groove drum have the above characteristics.It has wide application range.It can be applied in the avation,shipbuilding,offshore crane industry,oil field,coal,port,marine platform,construction,railway and other heavy machinery field.



Our efforts

In the process of production and operation, we adhering to the "pursuit of excellence, excellence" concept and deep cooperation with domestic and foreign universities, research institutes, formed a "production, use, collaborative innovation" model of development, rigorous scientific method and the specialization of production, the combination of constantly absorbing new technology improved product of research and development, producing a batch of and a batch of high quality products suitable for the market



Outline Structure Of Drawing



LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 0

LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 1LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 2

Processing Technic

LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 3

LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 4

LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 5LBS Grooved 350mm Diameter Winding Drum For Hoisting Winch 6
