Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material

Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material
Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material

Large Image :  Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: LBSS Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Export Standard Wooden Case
Delivery Time: General Order 15-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Pieces Per Month
Detailed Product Description
Product Name: Insulating Non-Static Material Nylon Split Drum Cover LEBUS Sleeves Material: Nylon
Groove Type: Lebus Grooves Sleeves Type: Split Type And Insulating Non-Static
Structure: Smooth Drum And Grooved Sleeves Connection Type: Bolted
Dia.of Rope: 2~80mm Layers: 2~60 Layers
Grooving Machining: CNC Machining Guarantee Period: 12 Months
High Light:

insulating lebus sleeve

,

non-static material lebus sleeve

,

split drum cover lebus sleeve

Insulating Non-Static Material Nylon Split Drum Cover LEBUS Sleeves

Sleeve is the best way to save money

The way to save money is to use a smooth drum and an outer bushing with a groove for the line, cut the bushing horizontally in two parts and bolt or weld it to or weld it to the smooth drum. If a different type or specification of wire rope is used in the future, the bushing can be removed and replaced with a bushing designed for the new wire rope.
The lebus groove system ensures that the multi-layer winding wire rope on the reel is completely smooth into and out of the drum, and can greatly prolong the life of the wire rope. This system is still the most effective and perfect method. Tests have shown that the Lebus drum can extend the wire rope with a rope groove matching the specifications of the wire rope.



The advantages of nylon

1. High mechanical strength, good toughness, high tensile and compressive strength. Its specific tensile strength is higher than that of metal, and its compressive strength is similar to that of metal, but its rigidity is not as good as that of metal.
2. Outstanding fatigue resistance, parts after repeated bending can still maintain the original mechanical strength.
3. High softening point, heat resistance (such as nylon 46, high crystalline nylon thermal deformation temperature is high, can be used for a long time in 150 degrees. PA66 after glass fiber reinforced, its thermal deformation temperature of 250 degrees or above).

7. Excellent electrical performance. Good electrical insulation, nylon volume resistance is very high, breakdown voltage resistance is high, in dry environment, can be used as working frequency insulation material, even in high humidity environment still has good electrical insulation.
8. Light weight, easy to dye, easy to shape.



Product lookview
GROOVING TYPE Insulating Non-Static Material Nylon Split Drum Cover LEBUS Sleeves
PRODUCT OTHER NAME groove sleeve
PROCESSING EQUIPMENT CNC machining center
DRUM GROOVE ROTATION Lefthand ,Righthand
SLING TYPE Wire rope or cable
ROPE CAPACITY 20-1000M
PRODUCT OTHER NAME LBS groove drum or winch drum
GROOVING TYPE LBS groove
PROCESSING EQUIPMENT CNC machining center
DRUM GROOVEROTATION Lefthand ,Righthand
SLING TYPE Wire rope or cable

Technical parameters and application
No Wire diameter(mm) Rotation direction Main drum
diameter(mm)
Main drum length(mm) Application
1 8 10 13 Lefthand,Righthand 430 763 The oil workover rig winch,
Towing winch
Tower crane
2 13 18 20 Lefthand,Righthand 623 1144 Engineering winch,
Lifting winch,Crawler crane
3 22 25 26 Lefthand,Righthand 730 1220 Oil workover rig ,
Logging Winch
4 18 22 32 Lefthand,Righthand 670 1240 Drilling Rig Winch,
drawworks
5 28 32 36 40 Lefthand,Righthand 560 630 Rotating Drilling Rig winch,
Lifting equipment
6 26 28 32 45 Lefthand,Righthand 760 1146 1970 1765 Offshore Crane,
Marine crane,Mooring winch

Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material 0Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material 1



Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material 2Insulating Non Static Split Drum Cover Lebus Sleeve Nylon Material 3
