Product Details:
Payment & Shipping Terms:
|
| Product Name: | LEBUS Groove Sleevs | Material: | Polymer Nylon And Steel |
|---|---|---|---|
| Groove Type: | Lebus Grooves | Surface Treatment: | Spray Zinc Rich Primer |
| Surface Color: | Customized | Connection Type: | Welded Or Bolted |
| Dia.of Rope: | 2~80mm | Layers: | 2~22 Layers |
| Used: | Hoist Drum | Grooving Machining: | CNC Machining |
| Advantage: | Prevent Wire Rope | Application: | Oilfield Equipment |
| High Light: | multi layer lebus groove sleeve,polymer nylon steel lebus groove sleeve,multi layer lebus sleeve |
||
The technical and economical advantages and benefits are clearly visible!
Safety during spooling operation
Considerable increase of wire rope life
Efficient and money-saving solution
Space saving with the LEBUS system
| PRODUCT NAME | multi-layer wire rope of cable onto hoisting drum spooling system lebus sleeves |
| PRODUCT OTHER NAME | Lebus groove sleeve |
| PROCESSING EQUIPMENT | CNC machining center |
| DRUM GROOVE ROTATION | Lefthand ,Righthand |
| SLING TYPE | Wire rope or cable |
| ROPE CAPACITY | 50-1000M |
| PRODUCT OTHER NAME | LBS groove drum or wire rope drum |
| MATERAIL | High polymer nylon or carbon steel |
| GROOVING TYPE | Lebus groove |
| WARRANTY | 1year |
| No: | Wire diameter(mm): | Rotation direction | Main drum diameter(mm) |
Main drum length(mm) | Application |
| 1 | 8 10 13 | Lefthand,Righthand | 430 | 763 | The oil workover rig winch, Towing winch Tower crane |
| 2 | 13 18 20 | Lefthand,Righthand | 623 | 1144 | Engineering winch, Lifting winch,Crawler crane |
| 3 | 22 25 26 | Lefthand,Righthand | 730 | 1220 | Mining winch Logging Winch |
| 4 | 18 22 32 | Lefthand,Righthand | 670 | 1240 | Drilling Rig Winch, drawworks |
| 5 | 28 32 36 40 | Lefthand,Righthand | 560 | 630 | Rotating Drilling Rig winch, Lifting equipment |
| 6 | 26 28 32 45 | Lefthand,Righthand | 760 1146 | 1970 1765 | Offshore Crane, Marine crane,Mooring winch |
