Polymer Nylon Lebus Sleeve For Logging Winch

Polymer Nylon Lebus Sleeve For Logging Winch
Polymer Nylon Lebus Sleeve For Logging Winch Polymer Nylon Lebus Sleeve For Logging Winch Polymer Nylon Lebus Sleeve For Logging Winch

Large Image :  Polymer Nylon Lebus Sleeve For Logging Winch

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: LBSS Series
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Export Standard Wooden Case
Delivery Time: General Order 15-30 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Pieces Per Month
Detailed Product Description
Product Name: LUBUS Sleeves Material: Polymer Nylon
Groove Type: Lebus Grooves Surface Treatment: Spray Zinc Rich Primer
Surface Color: Customized Connection Type: Welded Or Bolted
Dia.of Rope: 2~80mm Layers: 2~22 Layers
Used: Hoist Drum Grooving Machining: CNC Machining
Advantage: Prevent Wire Rope Application: Logging Winch
Highlight:

polymer nylon lebus sleeve

,

logging winch lebus sleeve



Polymer Nylon Materail Energy Saving And Insulation Lebus Sleeves For Logging Winch



Product advantage:
Compared with the general non grooved (smooth) drum and spiral grooved drum, the Grooved Steel Drum Sleeves has obvious advantages in the neat winding of multi-layer steel wire rope. Lbs double fold rope groove makes the winding of steel wire rope more smooth and the load between layers is evenly distributed, reduces the irregular, disorderly winding and rope biting in the process of steel wire rope arrangement, reduces the damage of steel wire rope, prolongs the service life of steel wire rope, improves the safety of equipment operation, and avoids the shutdown time of mechanical equipment due to disorderly rope replacement.



Product lookview:
PRODUCT NAME multi-layer wire rope of cable onto hoisting drum spooling system lebus sleeves
PRODUCT OTHER NAME Lebus groove sleeve
PROCESSING EQUIPMENT CNC machining center
DRUM GROOVE ROTATION Lefthand ,Righthand
SLING TYPE Wire rope or cable
ROPE CAPACITY 50-1000M
PRODUCT OTHER NAME LBS groove drum or wire rope drum
MATERAIL High polymer nylon or carbon steel
GROOVING TYPE Lebus groove
WARRANTY  1year


Technical parameters and application:
No: Wire diameter(mm): Rotation direction Main drum
diameter(mm)
Main drum length(mm)        Application
1 8 10 13 Lefthand,Righthand 430 763 The oil workover rig winch,
Towing winch
Tower crane
2 13 18 20 Lefthand,Righthand 623 1144 Engineering winch,
Lifting winch,Crawler crane
3 22 25 26 Lefthand,Righthand 730 1220 Mining winch
Logging Winch
4 18 22 32 Lefthand,Righthand 670 1240 Drilling Rig Winch,
drawworks
5 28 32 36 40 Lefthand,Righthand 560 630 Rotating Drilling Rig winch,
Lifting equipment
6 26 28 32 45 Lefthand,Righthand 760 1146 1970 1765 Offshore Crane,
Marine crane,Mooring winch



Polymer Nylon Lebus Sleeve For Logging Winch 0Polymer Nylon Lebus Sleeve For Logging Winch 1Polymer Nylon Lebus Sleeve For Logging Winch 2



Polymer Nylon Lebus Sleeve For Logging Winch 3

Polymer Nylon Lebus Sleeve For Logging Winch 4

Polymer Nylon Lebus Sleeve For Logging Winch 5Polymer Nylon Lebus Sleeve For Logging Winch 6
