Product Name: | Cabel Winch Drum | Drum Quantity: | Single Or Double |
---|---|---|---|
Drum Design: | Smooth Or Lebus | Material: | Q355b |
Application Range: | Lifting Equipment | Power Source: | Electric |
Rope Capacity: | 550mm | Rope Diameter: | 10mm |
Certification: | Ccs | The Connection Method: | Welding Or Bolt |
Highlight: | lifting and pulling cable winch drum,electric power crane wire rope drum,lifting pulling crane wire rope drum |
Product name | Cable winch drum |
Drum Quantity | Single Or Double |
Drum Design | LBS Groove Or Spiral Groove |
Material | Carbon Stainless And Alloy Steels |
Size | Customization |
Application Range | Construction Mining Terminal operation |
Power Source | Electric and hydraulic |
Rope Capacity | 100~300M |
Grooved Winch Drum Material: Carbon Steel, Alloy Steel, Stainless Steel, Aluminum, High-Strength Steel, Etc
Material Standards: GB, AISI, ASME, ASTM, JIS, DIN, ...
Ambient Temperature: -40 ° C To +45 ° C
Stroage Ambient Temperature: -40 ° C To +50 ° C
Groove Type of Drum: Spiral Grooves or Lebus Grooves
The Rotation Direction of The Drum: Lefthand or Righthand
Processing method: Machine Work
Wire Rope Diameter: 3 MM~100 MM
Processing Equipment: CNC machining center
No: | Wire diameter(mm) | Pulling Force(KN) | Rotation Direction | Drum Diameter(mm) | Drum Length(mm) |
1 | 3~8 | 3~10 | Lefthand,Righthand | >160 | <1000 |
2 | 10~16 | 12~20 | Lefthand,Righthand | >320 | <1000 |
3 | 18~24 | 20~80 | Lefthand,Righthand | >480 | <1000 |
4 | 26~32 | 100~120 | Lefthand,Righthand | >640 | <1000 |
5 | 34~40 | 150~200 | Lefthand,Righthand | >800 | <1000 |
6 | 42~50 | 240~400 | Lefthand,Righthand | >1000 | <1000 |
1. Our products have the advantages of compact structure, light weight, safe and easy to operate.
2. Our products are used for general lifting, hauling and other works in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery and etc.
3. Products are designed and manufactured according to API Spec 7K “Specification for Drilling Equipment”.
4. High starting& working efficiency
5. Reliable operation with little noise
1) Wire rope or cable diameter (mm)
2) The main drum diameter (mm)
3) Width between flanges (mm)
4) Length of rope or cable to be accommodated
5) Material and requirements of the drum
6) Maximum operating load on rope or cable
7) Direction of wire rope entry
8) Type of rope entry
9) Distance to fixed sheave and position between flanges
10) Outside diameter of flanges
CNC machining center
1. Carbon structural steel: Q235A/B/C/D/E SS400 A36 SM400 St37-2 S235J...
2. Low alloy high strength steel: Q345A/B/C/D/E Q390 Q420 Q460 15GrMo 20GrMo 12GrMoVNi 42GrMo...
3. Alloy structural steel: 20Mn2 40Mn2 15Cr 30Cr 20CrMnMo 20CrNi...
4. Polymer materials, fiber materials and polyamide nylon materials.
5. Stainless steel materials, aluminum materials, etc.
The product material can be selected according to the customer's request
Processing Equipment: CNC Machining Center
Rotation Direction Of Grooves: Lefthand
Wire Rope Diameter: 3 MM~65 MM
Each Layer Laps: 20.5 laps
Layer: 5 Layer
Rope Groove Type: LEBUS Rope Groove
Number Of Ropes: Two
As early as 2010, the company obtained the utility model patent certificate suitable for multi-layer winding double folding cable groove, and registered the LBS trademark in 2013.
Passed iso9001:2015 quality management system certification in 2017;
In 2018, it passed the GJB9001C-2017 weapon equipment quality management system certification.
In 2019, the company was identified as a science and technology smes in Hebei Province.
In recent years, the company with strong technical strength, advanced production equipment, strict quality control system, achieved rapid development.
In addition, the products are also exported to the United States, Britain, Spain, Germany, France, Italy, Denmark and other European and American countries, as well as Japan, South Korea, Singapore, Australia and other Asia-pacific countries.
In the process of production and operation, we adhering to the "pursuit of excellence, excellence" concept and deep cooperation with domestic and foreign universities, research institutes, formed a "production, use, collaborative innovation" model of development, rigorous scientific method and the specialization of production, the combination of constantly absorbing new technology improved product of research and development, producing a batch of and a batch of high quality products suitable for the market,
Our factory has more than 2000 sets of advanced equipment such as casting, forging, gear processing, sheet metal stamping, riveting, heat treatment and mechanical processing. In recent years, the Germany CW1000 machining center, CNC four axis, five axis linkage machining center, CNC punch, large CNC hobbing gear grinding machine, large CNC floor boring and milling machine, Vacuum electron beam welding, CNC welding robot and 80 roll machine and other advanced processing equipment
Wire rope diameter or cable diameter(mm)
Inner diameter D1(mm)
Outer diameter D2(mm)
Width between the flanges L(mm)
Rope capacity(m)
Material:
Rotation direction:left or right?
