Product Details:
Payment & Shipping Terms:
|
| Product Name: | LEBUS Grooved Cabel Winch Drum | Drum Quantity: | Quadruple |
|---|---|---|---|
| Drum Design: | Lebus Grooved | Material: | Q355D |
| Application Range: | Towing Winch | Rope Capacity: | 2500mm |
| Rope Diameter: | 10mm | Made Of: | Steel Plate Or Pipe |
| Highlight: | quadruple cable winch drum,lebus grooved cable winch drum |
||
| Product name | Zinc-plated quadruple LEBUS grooved cable drum can simultaneously coil and release rope |
| Drum Quantity | four |
| Drum Design | grooved |
| Material | Q355D |
| Size | Customization |
| Application Range | Construction Mining Terminal operation |
| Power Source | Electric and hydraulic |
| Rope Capacity | 100~300M |
multi-drum of the window washer
The hoist structure adopts the form of multi-drum, 4 independent galvanized steel cables are wound on the drum in multiple layers, and a rope arrangement mechanism is set up to ensure the smooth and uniform discharge of the rope and the close arrangement of the rope. The diameter of the drum is determined according to the working height of the window washer. The lifting height is 55M.
Technical Parameters
| No: | Wire diameter(mm) | Pulling Force(KN) | Rotation Direction | Drum Diameter(mm) | Drum Length(mm) |
| 1 | 3~8 | 3~10 | Lefthand,Righthand | >160 | <1000 |
| 2 | 10~16 | 12~20 | Lefthand,Righthand | >320 | <1000 |
| 3 | 18~24 | 20~80 | Lefthand,Righthand | >480 | <1000 |
| 4 | 26~32 | 100~120 | Lefthand,Righthand | >640 | <1000 |
| 5 | 34~40 | 150~200 | Lefthand,Righthand | >800 | <1000 |
| 6 | 42~50 | 240~400 | Lefthand,Righthand | >1000 | <1000 |
CNC machining center
