Hebei Junke Machinery Technology Co.,Ltd
Home ProductsOil Rig Drawworks

Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction

China Hebei Junke Machinery Technology Co.,Ltd certification
China Hebei Junke Machinery Technology Co.,Ltd certification
The company has a very mature technology, product quality is impeccable, the details of the deal well, look forward to the next cooperation.

—— Earlina Adamson

The equipment trades completed in March, the winch wire rope drum has been installed, wire rope neatly arranged, the equipment is in good condition.

—— Zhang Zhipeng Singapore

I'm Online Chat Now

Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction

Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction
Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction

Large Image :  Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: Non-standard
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 to 40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 150 sets per month
Detailed Product Description
Product Name: Oil Workover Rig Winch Drum Quantity: Double
Drum Design: LBS Groove Material: Carbon Stainless And Alloy Steels And High
Size: 10-800 Application Range: Mining , Construction , Road , Forest
Power Source: Hydraulic Or Electric Capacity: 500kn
Cor Component: Drum And Sleeve Supply Ability: 2000 Sets Per Month
High Light:

Lebus Winch Drum

,

Winch Drum Sleeves

,

Lebus winch Spare Parts

Non-Standard Oil Drilling Rig Drawwork Spare Parts Lebus Drum Sleeves




LBS grooved winch drum advantage:

1) Each one circle layer of the grooved drum has two parallel groove section and two groove section
2) Make wire rope spooling more smooth and uniform distribution of load between each layer
3) Prevent cross &mess in rope spooling working happening
4) Lower the rope damage, extend the rope life





Oil Driling Ring Drums Features:

1. Our products have the advantages of compact structure, light weight, safe and easy to operate.
2. Our products are used for general lifting, hauling and other works in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery and etc.
3. Products are designed and manufactured according to API Spec 7K “Specification for Drilling Equipment”.
4. High starting& working efficiency
5. Reliable operation with little noise



About us:

Shijiazhuang Jun Zhong Machinery Maufacturing Co.,Ltd has been certified as “High & New-tech Enterprises of Hebei Province”, “benchmark enterprises”, “Well-known Trademark of China”, “Famous Trademark of Hebei Province”, and it has achieved many patents of state level and National Torch Plan Projects.



Techinical parameters:

No: Wire diameter(mm) Pulling Force(KN) Rotation Direction Drum Diameter(mm) Drum Length(mm)
1 3~8 3~10 Lefthand,Righthand >160 <1000
2 10~16 12~20 Lefthand,Righthand >320 <1000
3 18~24 20~80 Lefthand,Righthand >480 <1000
4 26~32 100~120 Lefthand,Righthand >640 <1000
5 34~40 150~200 Lefthand,Righthand >800 <1000
6 42~50 240~400 Lefthand,Righthand >1000 <1000



Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction 0

Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction 1Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction 2Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction 3

Reliable Lebus Winch Drum Sleeves Winch Spare Parts For Construction 4
