Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification

Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification
Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification

Large Image :  Onshore Large Oil Rig Drawworks Electric Drilling With CCS Certification

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: customizable
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 20 to 30 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 150 sets per month
Detailed Product Description
Product Name: Oil Rig Drawworks Drum Quantity: Single Or Double
Drum Design: LBS Groove Or Spiral Groove Material: Carbon Stainless And Alloy Steels
Size: Customization Application Range: Shipyard Oil Mining
Power Source: Hydraulic Or Electric Capacity: 500kn
Third Party Inspection: Available Grade: The Best
Highlight:

Onshore Oil Rig Drawworks

,

Large Oil Rig Drawworks

,

CCS heavy duty hydraulic winch

High Quality Cost-Effective Electric Drilling Onshore Large Oil Rig Drawworks





Product information

Usage: Oil Well

Applicable Industries: Energy & Mining

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: New Product 2020

Warranty of core components: 1 Year

Core Components: Engine, Motor, Pump

Condition: New

Type: Rotary Drilling Rig

Power Type:Electric or Hydraulic

Place of Origin: China

Brand Name: LBS

Model Number:750HP -900HP drilling rig

Voltage: 380V

Warranty: 1 Year

Product name: Drilling Rig

Application: Oil Drilling Rig

Drilling Depth: 1000-9000 meters

Classfication: Electrical/Mecahnical/Mechan-Electrical Rig

Model: 750HP-3000HP Rig

Key words: Drilling Rig/Workover

Product Category: as per customer's requirement

Engine: Electric Or Hydraulic

Meterial: Steel

After-sales Service Provided: Online support, Video technical support, Field installation, commissioning and training, Field maintenance and repair service

Certification: CCS

colour :red or require

Sling type:cable or wire
Power :electric or hydraulic
Rope capacity:1~10000m
Rope diameter:3~90MM
Winch drum type:LBS groove

Customization need more product technical parameters.



Drum features:

Product adoption LBS grooved drum, LBS groove system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.High quality Cost-effective Electric Drilling Onshore Large Load Workover Rig



Techinical parameters:



technical parameters
input powerkW JZ05 JZ03 JZ10-2 JZ08-02 JZ02-09 JZ3-2 JZ50D
150 180 400 450 600 735 1100
master rotor Maximum Fast line tension(second floor)kN 80 120 180 210 280 275 340
diameter of the tube body x lengthmm Φ345×590 Φ356×912 Φ450×912 Φ450×912 Φ580×1012 Φ640×1237 Φ685×1138
brake drum (disc) diameter x length (thickness)mm Φ810×210 Φ970×260 Φ1070×310 Φ1070×310 Φ1168×267 Φ1168×265 Φ1600×76
For wire rope diameter mm 22 22 29 29 32 32 35
maximum speed of revolutionrpm 450 450 450 450 450 370 370
brake drum cooling way air cooling air cooling Forced circulating water cooling Forced circulating water cooling Forced circulating water cooling Forced circulating water cooling air cooling



High Quality Cost-Effective Electric Drilling Onshore Large Oil Rig Drawworks

About us:



Shijiazhuang Jun Zhong Machinery Maufacturing Co.,Ltd has been certified as “High & New-tech Enterprises of Hebei Province”, “benchmark enterprises”, “Well-known Trademark of China”, “Famous Trademark of Hebei Province”, and it has achieved many patents of state level and National Torch Plan Projects.
