Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope

Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope
Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope

Large Image :  Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: customizable
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 20 to 30 working days, depends on order amounts and specification
Payment Terms: L/C, T/T
Supply Ability: 150 sets per month
Detailed Product Description
Product Name: Oil Workover Rig Winch Core Component: Drum
Drum Quantity: Single Drum Design: LBS Groove
Material: Carbon Stainless Size: Customization
Application Range: Shipyard Oil Mining Power Source: Hydraulic Or Electric
Capacity: 500kn Grade: The Best
Highlight:

carbon steel lebus drum

,

rotary oil driling rig lebus drum

,

drawworks wound wire rope lebus drum

Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope

Signle / Double Drum Winch​ description

colour: red or require
Sling type: cable or wire
Power: electric or hydraulic
Rope capacity: 1~10000m
Rope diameter: 3~90MM
Winch drum type: LBS grooves

Customization need more product technical parameters.



Drum features



Product adoption LBS grooved drum, LBS groove system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.



Techinical parameters



technical parameters
input powerkWJZ05JZ03JZ10-2JZ08-02JZ02-09JZ3-2JZ50D
1501804004506007351100
master rotorMaximum Fast line tension(second floor)kN80120180210280275340
diameter of the tube body x lengthmmΦ345×590Φ356×912Φ450×912Φ450×912Φ580×1012Φ640×1237Φ685×1138
brake drum (disc) diameter x length (thickness)mmΦ810×210Φ970×260Φ1070×310Φ1070×310Φ1168×267Φ1168×265Φ1600×76
For wire rope diameter mm22222929323235
maximum speed of revolutionrpm450450450450450370370
brake drum cooling wayair coolingair coolingForced circulating water coolingForced circulating water coolingForced circulating water coolingForced circulating water coolingair cooling



Company introduction

Our company early introduction of advanced technology at home and abroad, after years of research and development and improvement, in the hoisting machinery multi-layer wire rope row rope field has made a major breakthrough.

In 2010, the company obtained the production patent of double folding rope groove drum, and founded its own brand - LBS. At present, the company has formed a mature and stable, serializedproduct production mode.

When the split type drum fence skin is installed, the split fence skin sleeve is wrapped on the smooth slotless drum, and is closely connected with the drum through bolts or welding, so that the original smooth surface of the drum outside the surface becomes the form of lebus double folding rope groove, which is convenient for the application of winch modification or replacement of the drum.

Our factory has more than 2000 sets of advanced equipment such as casting, forging, gear processing, sheet metal stamping, riveting, heat treatment and mechanical processing. In recent years, the Germany CW1000 machining center, CNC four axis, five axis linkage machining center, CNC punch, large CNC hobbing gear grinding machine, large CNC floor boring and milling machine, Vacuum electron beam welding, CNC welding robot and 80 roll machine and other advanced processing equipment.

Our Service

a.Our company specialized in design and produce various types of electric and hydraulic anchor windlass , mooring winch, luffing crane and boat plane and rack, winch, engineering winch, cable winch and towing winch(The main drum is used grooved drum).
b.One year of warranty.
c.The engineer can provide overseas service.
d.Quick and responsible after-sales service.
e.Very competitive price.
f.Before sending the goods, we will test and adjust, so you can use directly when you get it.
g.Operation video & instruction will be sent to clients, to help them use the sleeves better. Additionally, our company provides technical support and fittings for life.
h.Any problems occur while using, professional advice will be offered.
i.All kinds of frequently used parts are supplied all the year round.

Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope 0

Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope 1
Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope 2Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope 3Carbon Steel Lebus Drum For Rotary Oil Driling Rig Drawworks To Wound Wire Rope 4
