Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks

Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks
Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks

Large Image :  Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: customizable
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 20 to 30 working days, depends on order amounts and specification
Payment Terms: L/C, T/T
Supply Ability: 150 sets per month
Detailed Product Description
Product Name: Oil Rig Drawworks Drum Quantity: Single
Drum Design: LBS Groove Material: Carbon Stainless And Alloy Steels
Application Range: Shipyard Oil Mining Power Source: Hydraulic Or Electric
Capacity: 500kn Core Component: Drum
Supply Ability: 2000sets Per Month Warranty: 1year
High Light:

Truck Mounted hydraulic workover unit

,

120ton hydraulic workover unit

,

120ton hydraulic work over unit

Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks

Oil Rig Drawworks information



Usage: Oil Well

Applicable Industries: Energy & Mining

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: New Product 2020

Warranty of core components: 1 Year

Core Components: Engine, Motor, Pump

Condition: New

Type: Rotary Drilling Rig

Power Type: Electric or Hydraulic

Place of Origin: China

Brand Name: LBS

Model Number: 750HP -900HP drilling rig

Voltage: 380V

Warranty: 1 Year

Product name: Drilling Rig

Application: Oil Drilling Rig

Drilling Depth: 1000-9000 meters

Classfication: Electrical/Mecahnical/Mechan-Electrical Rig

Model: 750HP-3000HP Rig

Key words: Drilling Rig/Workover

Product Category: as per customer's requirement

Engine: Electric Or Hydraulic

Meterial: Steel



Drum features



Product adoption LBS grooved drum, LBS groove system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.



Techinical parameters



technical parameters
input power(kW) JZ05 JZ03 JZ10-2 JZ08-02 JZ02-09 JZ3-2 JZ50D
150 180 400 450 600 735 1100
master rotor Maximum Fast line tension(second floor)kN 80 120 180 210 280 275 340
diameter of the tube body x lengthmm Φ345×590 Φ356×912 Φ450×912 Φ450×912 Φ580×1012 Φ640×1237 Φ685×1138
brake drum (disc) diameter x length (thickness)mm Φ810×210 Φ970×260 Φ1070×310 Φ1070×310 Φ1168×267 Φ1168×265 Φ1600×76
For wire rope diameter mm 22 22 29 29 32 32 35
maximum speed of revolutionrpm 450 450 450 450 450 370 370
brake drum cooling way air cooling air cooling Forced circulating water cooling Forced circulating water cooling Forced circulating water cooling Forced circulating water cooling air cooling





About us



Shijiazhuang Jun Zhong Machinery Maufacturing Co.,Ltd has been certified as “High & New-tech Enterprises of Hebei Province”, “benchmark enterprises”, “Well-known Trademark of China”, “Famous Trademark of Hebei Province”, and it has achieved many patents of state level and National Torch Plan Projects.



Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks 0

Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks 1Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks 2

Heavy Duty 120ton Truck-Mounted Workover Rig For Oil Rig Drawworks 3
