Ship Use 10 Ton Winch With Spooling Device CCS Certification

China Hebei Junke Machinery Technology Co.,Ltd certification
China Hebei Junke Machinery Technology Co.,Ltd certification
The company has a very mature technology, product quality is impeccable, the details of the deal well, look forward to the next cooperation.

—— Earlina Adamson

The equipment trades completed in March, the winch wire rope drum has been installed, wire rope neatly arranged, the equipment is in good condition.

—— Zhang Zhipeng Singapore

I'm Online Chat Now

Ship Use 10 Ton Winch With Spooling Device CCS Certification

Ship Use 10 Ton Winch With Spooling Device CCS Certification
Ship Use 10 Ton Winch With Spooling Device CCS Certification Ship Use 10 Ton Winch With Spooling Device CCS Certification Ship Use 10 Ton Winch With Spooling Device CCS Certification

Large Image :  Ship Use 10 Ton Winch With Spooling Device CCS Certification

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: ccs
Model Number: Custom-Made
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD, EUR, RMB / Negotiable
Packaging Details: Steel Pallet
Delivery Time: General order 30-50 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 Pieces Per Month
Detailed Product Description
Product Name: Winch With Spooling Device Capacity: 10T~15T
Application: Ship Power Source: Electric Or Hydraulic
Material: Steel Q355D Brand Name: LBS
Warranty: 1year Grade: The Best
Supply Ability: 2000 Sets Per Month Packing: Fumigation -free Pallet
High Light:

CCS Winch With Spooling Device

,

10 Ton Winch With Spooling Device

,

CCS 10 ton winch

Customized Hydraulic Hauling Fishing Net Winch With Spooling Device



No: Wire diameter(mm) Pulling Force(KN) Rotation Direction Drum Diameter(mm) Drum Length(mm)

1


3~8 3~10 Lefthand,Righthand >160 <1000

2


10~16 12~20 Lefthand,Righthand >320 <1000

3


18~24 20~80 Lefthand,Righthand >480 <1000

4


26~32 100~120 Lefthand,Righthand >640 <1000

5


34~40 150~200 Lefthand,Righthand >800 <1000

6


42~50 240~400 Lefthand,Righthand >1000 <1000


Product name

Cable winch drum


Drum Quantity

Single Or Double


Drum Design

LBS Groove Or Spiral Groove


Material

Carbon Stainless And Alloy Steels


Size

Customization


Application Range

Construction Mining Terminal operation


Power Source

Electric and hydraulic


Rope Capacity

100~300M




Product Features:

1. Steel Wire rope electric winch with spooling system
2. Automatic rope arrangement can be realized
3. Compact structure and reasonable design
4. Keep the wire rope's tensioning tight for winches & cranes
5. The spooling machine can supply a back force on the rope to keep the rope a tensioning force.The spooling machine and its HPU are removeable



Spooling device:


1. The rope winding device of the winch (spooling device winch) adopts the principle of double rotating screw to drive the rope wheel to move back and forth,It is mechanical transmission device, easy to use, safe and reliable.
2. The winch rope arranging device consists of six parts, namely, power output part, transmission box, clutch, spiral sleeve part, rope supporting part and base.
3. In the installation process, does not require any part of the transformation of the winch, only needs to install the outer gear on the winch motor side, the power of the motor output.



Drive principle:



Winch drum - gear box - screw sleeve rotation - rope wheel reciprocating movement.



Company introduction



Our company early introduction of advanced technology at home and abroad, after years of research and development and improvement, in the hoisting machinery multi-layer wire rope row rope field has made a major breakthrough,



In 2010, the company obtained the production patent of double folding rope groove drum, and founded its own brand - LBS. At present, the company has formed a mature and stable, serializedproduct production mode.



When the split type drum fence skin is installed, the split fence skin sleeve is wrapped on the smooth slotless drum, and is closely connected with the drum through bolts or welding, so that the original smooth surface of the drum outside the surface becomes the form of lebus double folding rope groove, which is convenient for the application of winch modification or replacement of the drum.



Our factory has more than 2000 sets of advanced equipment such as casting, forging, gear processing, sheet metal stamping, riveting, heat treatment and mechanical processing. In recent years, the Germany CW1000 machining center, CNC four axis, five axis linkage machining center, CNC punch, large CNC hobbing gear grinding machine, large CNC floor boring and milling machine,Vacuum electron beam welding, CNC welding robot and 80 roll machine and other advanced processing equipment.



Our Service



All products purchased in our company are guaranteed to keep in good repair for one year.
If quality problems happen in guarantee period, our company will maintain for free.
a. Before sending the machine, we will test and adjust, so you can use directly when you get it.
b. Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we
will solve your problems in time.
If you are caught in some problems when using our products, welcome to contact us at any time.
a. Any problems occur while using, professional advice will be offered.
b. All kinds of frequently used parts are supplied all the year round.
