CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch

CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch
CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch

Large Image :  CCS Certified Heavy Duty Ship Anchor Winch , 20 Ton Hydraulic Winch

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: ccs
Model Number: Custom-Made
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD, EUR, RMB / Negotiable
Packaging Details: Steel Pallet
Delivery Time: General order 30-50 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 Pieces Per Month
Detailed Product Description
Product Name: Winch With Spooling Device Capacity: 10T~15T
Application: Off Shore Power Source: Electric Or Hydraulic
Material: Steel Q355D Place Of Origin: China
Capacity: 20TON Warranty: 1 Year
High Light:

CCS ship anchor winch

,

20 ton ship anchor winch

,

CCS 20 ton hydraulic winch

20 Ton Best Design Ship Variable Speed Winch with Spooling Device

Product introduction

The manual winch with cable arrangement device includes winch module, transmission module and cable arrangement module. The cable arrangement module includes reciprocating lead screw, optical shaft, transmission nut, guide wheel, guide fixed rod and fixed plate.



The reciprocating lead screw and optical shaft are arranged in parallel with the drum shaft in the winch module, and the drum shaft is connected with the reciprocating lead screw through the transmission module, Drive the reciprocating lead screw and the drum transmission shaft to rotate together according to a certain transmission ratio, the transmission nut is rotationally connected with the reciprocating lead screw, the transmission nut is sleeved on the optical shaft, the fixing plate is placed above the transmission nut, the two guide wheels are respectively fixed on the fixing plate through the guide wheel fixing rod and butterfly nut, the two guide wheels are close to each other, and a guide hole for cables is formed in the middle. The utility model has the advantages of simple and compact structure, convenient maintenance, orderly cable arrangement, improved cable arrangement efficiency and low cost.



20 Ton Best Design Ship Variable Speed Winch with Spooling Device



No: Wire diameter(mm) Pulling Force(KN) Rotation Direction Drum Diameter(mm) Drum Length(mm)

1

3~8 3~10 Lefthand,Righthand >160 <1000

2

10~16 12~20 Lefthand,Righthand >320 <1000

3

18~24 20~80 Lefthand,Righthand >480 <1000

4

26~32 100~120 Lefthand,Righthand >640 <1000

5

34~40 150~200 Lefthand,Righthand >800 <1000

6

42~50 240~400 Lefthand,Righthand >1000 <1000



Product name

Cable winch drum

Drum Quantity

Single Or Double

Drum Design

LBS Groove Or Spiral Groove

Material

Carbon Stainless And Alloy Steels

Size

Customization

Application Range

Construction Mining Terminal operation

Power Source

Electric and hydraulic

Rope Capacity

100~300M




Product Features:

1. Steel Wire rope electric winch with spooling system

2. Automatic rope arrangement can be realized

3. Compact structure and reasonable design

4. Keep the wire rope's tensioning tight for winches & cranes

5. The spooling machine can supply a back force on the rope to keep the rope a tensioning force.The spooling machine and its HPU are removeable



Spooling device:

1. The rope winding device of the winch (spooling device winch) adopts the principle of double rotating screw to drive the rope wheel to move back and forth,It is mechanical transmission device, easy to use, safe and reliable.

2. The winch rope arranging device consists of six parts, namely, power output part, transmission box, clutch, spiral sleeve part, rope supporting part and base.

3. In the installation process, does not require any part of the transformation of the winch, only needs to install the outer gear on the winch motor side, the power of the motor output.



Drive principle:



Winch drum - gear box - screw sleeve rotation - rope wheel reciprocating movement.



Our Service



All products purchased in our company are guaranteed to keep in good repair for one year.
If quality problems happen in guarantee period, our company will maintain for free.
a. Before sending the machine, we will test and adjust, so you can use directly when you get it.
b. Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we
will solve your problems in time.
If you are caught in some problems when using our products, welcome to contact us at any time.
a. Any problems occur while using, professional advice will be offered.
b. All kinds of frequently used parts are supplied all the year round.



Company introduction



Our company early introduction of advanced technology at home and abroad, after years of research and development and improvement, in the hoisting machinery multi-layer wire rope row rope field has made a major breakthrough,



In 2010, the company obtained the production patent of double folding rope groove drum, and founded its own brand - LBS. At present, the company has formed a mature and stable, serializedproduct production mode.



When the split type drum fence skin is installed, the split fence skin sleeve is wrapped on the smooth slotless drum, and is closely connected with the drum through bolts or welding, so that the original smooth surface of the drum outside the surface becomes the form of lebus double folding rope groove, which is convenient for the application of winch modification or replacement of the drum.



Our factory has more than 2000 sets of advanced equipment such as casting, forging, gear processing, sheet metal stamping, riveting, heat treatment and mechanical processing. In recent years, the Germany CW1000 machining center, CNC four axis, five axis linkage machining center, CNC punch, large CNC hobbing gear grinding machine, large CNC floor boring and milling machine,Vacuum electron beam welding, CNC welding robot and 80 roll machine and other advanced processing equipment.
