Double Drum 2t / 3tm Electric Rope Winch For Construction Mining

Double Drum 2t / 3tm Electric Rope Winch For Construction Mining
Double Drum 2t / 3tm Electric Rope Winch For Construction Mining Double Drum 2t / 3tm Electric Rope Winch For Construction Mining Double Drum 2t / 3tm Electric Rope Winch For Construction Mining

Large Image :  Double Drum 2t / 3tm Electric Rope Winch For Construction Mining

Product Details:
Place of Origin: Shijiazhuang Hebei China
Brand Name: LBS
Certification: CCS
Model Number: LBSW-E
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 to 40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 500 Pieces/Sets Per Month
Detailed Product Description
Product Name: Electric Power Winch Material: Steel
MOQ: 1 Set Produce Equipment: CNC Center
Drum Quantity: Double Application Range: Construction
Hoist Speed: 0.95-1.27m/s Rotate Speed: 720-960 R/min
Rope Diameter: 2.5-30mm Direction Rotation: Left Or Right
Highlight:

2t electric rope winch

,

3m electric rope winch

,

double drum electric wire rope winch

Double Drum 2T / 3Tm Electric Winch For Construction Or Mining





Product introduce

Usage: Construction Or Mining

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: New Product

Warranty of core components: 1 Year

Core Components: Engine, Motor and drum

Condition: New

Power Type: Electric

Place of Origin: China

Brand Name: LBS

Voltage: 220V or 380V or 400V

Warranty: 1 Year

Carrying Capaty: 10-300meters

KEy words: electric winch

Product Category: as per customer's requirement

Engine: Electric

Meterial: Steel

After-sales Service Provided: Online support, Video technical support, Field installation, commissioning and training, Field maintenance and r                        epair service

Certification: CCS



Property
Place of origin HEBEI,CHINA
Customized YES
Model 201903260858
Type 1T*30m,2T*30m,3T*30m,5T*30m,10T*30m
1T*60m,2T*60m,3T*60m,5T*60m,10T*60m
1T*100m,2T*100m,3T*100m,5T*100m,10T*100m
1T*150m,2T*150m,3T*150m,5T*150m,10T*150m
Rope capacity 30-100(m)
Winch type double drum electric winch
Brand LBS
Rope speed 8-16(m/min)
lifting capacity 1T-5T(kg)
N.W 260-310(kg)
Structural type in-line winch






Structure form

The winch converts the electric energy into mechanical energy through the motor, that is, the rotor of the motor rotates the output, through the triangle belt, shaft, gear, and then drives the drum to rotate after deceleration. The reel winds the wire rope 7 and passes through the pulley block to make the crane hook lift or drop the load Q, change the mechanical energy into mechanical work, and complete the vertical transport loading and unloading work of the load



Installation of electric winch

The most important note here is the state of the rope drum, which must be used to ensure that the lasso is evenly wound before the process begins. The installation process is as follows:

1. Plug in the remote control. Connect the distal end of the first plug-in winch.

2. Do not let the remote connection hang. If you are a driver, operate the remote control from the driver's seat and then make additional connections around the side mirrors of the car to make co-working easier.

3. Open the noose, use the remote control to open the noose a bit, and install it on the side of the electric winch.

Turn on the clutch. Please note that we have to open the hook later to open the clutch.

5. Hold the rope hook hand. Grabbing the hook with one hand pulls the rope out of the roller, so no matter how long the rope has been twisted, it doesn't reach the hook.

6. Pull the rope on the pivot and lock the clutch.

So the electric winch is installed.



Precautions for controlling electric winch

In practice, auxiliary tools such as gloves to keep hands safe are essential for safety and stability when using electric winches. Also, if you want to attach the electric winch to a tree and to a rope, hang the U-ear and tight wire pulley. Tape is used to hold the pivot. The ideal length is 1.5-2m. U-lug and belt and electric winch hook can be connected. It is therefore best to prepare lugs of several sizes. With two or three rows, drag to change direction, you need a tight pulley



Double Drum 2t / 3tm Electric Rope Winch For Construction Mining 0



Double Drum 2t / 3tm Electric Rope Winch For Construction Mining 1Double Drum 2t / 3tm Electric Rope Winch For Construction Mining 2Double Drum 2t / 3tm Electric Rope Winch For Construction Mining 3Double Drum 2t / 3tm Electric Rope Winch For Construction Mining 4
