Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable

China Hebei Junke Machinery Technology Co.,Ltd certification
China Hebei Junke Machinery Technology Co.,Ltd certification
The company has a very mature technology, product quality is impeccable, the details of the deal well, look forward to the next cooperation.

—— Earlina Adamson

The equipment trades completed in March, the winch wire rope drum has been installed, wire rope neatly arranged, the equipment is in good condition.

—— Zhang Zhipeng Singapore

I'm Online Chat Now

Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable

Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable
Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable

Large Image :  Fast Winding Rope 8mm Wire Pulling Winch Large Capacity Customizable

Product Details:
Place of Origin: Shijiazhuang ,Hebei ,China
Brand Name: LBS
Certification: ccs
Model Number: CUSTOMIZABLE
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD, EUR, RMB / Negotiable
Packaging Details: Export standard wooden case
Delivery Time: after advance 15-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Pieces Per Month
Detailed Product Description
Full Name: Electric Cable Pulling Winch Material: Alloy Steel
Color: Customizable Grooving Type: LBS Grooving Or Helical Grooving
Surface Hardness: As Your Requirement Use: Cable Winch
Rope Diameter: 6mm 8mm Cluth: Electric Or Hydrauli
High Light:

8mm wire pulling winch

,

wire pulling winch alloy steel

,

customizable electric cable pulling winch

customizable fast winding wire rope arge capacity Electric Cable Pulling Winch





Spooling concept

Spooling device is an important part of cable storage winch. The guide cables are arranged orderly on the drum of cable storage winch. It is mainly composed of screw, rope retractor and load-bearing beam. The screw of the cable drum and the cable setter rotates synchronously through the chain drive device. The screw is bi-directional thread and the lead is the diameter of the cable. The rope retractor consists of a small roller, a pulley baffle, a pulley and a slider nut, mounted on the bearing beam by a small roller. The rotation of the bi-directional screw causes the slider nut to move left and right along the axis of the screw with the retractor to guide the cable. In order to avoid bending deformation of the screw under excessive pressure, the load-bearing beam was analyzed by force and finite element method, and its strength and stiffness were calculated to meet the requirements.



Structure form

The winch converts the electric energy into mechanical energy through the motor, that is, the rotor of the motor rotates the output, through the triangle belt, shaft, gear, and then drives the drum to rotate after deceleration. The reel winds the wire rope 7 and passes through the pulley block to make the crane hook lift or drop the load Q, change the mechanical energy into mechanical work, and complete the vertical transport loading and unloading work of the load



Breif introduction

We also supply LBS grooved drum used in all kinds of winchs. The whole drum details as follows:

1. the groove is cut directly into the body of drum.

2. according to the customer' requirements, the flanges are either welded or screw-bolted.

3. the groove is available as either LBS-groove or helical-groove.

4. groove geometry is determined by rope construction, diameter and length ,and by application.

5. the drum is provided with the requested mounting dimensions to fit the flanges by welding or screw bolting.



Other products

Sleeves are used to prevent damage to a drum. It is usually cheaper to replace a worn out sleeve in stead of replacing or repair the complete drum assembly.
The LBS split-sleeve system consists of a pair of outer shells that are bolted or welded onto a smooth drum to provide a grooving pattern. either LBS parallel grooves can be carved into sleeves. As with all LBS drums, the grooving in split sleeves is engineer to much the specific rope construction, diameter and length, and to suit
We can design the LBS sleeve according to the drum's size and parameter.So the customer need to provide some paramter as follows:



Company introduction

Our factory has more than 2000 sets of advanced equipment such as casting, forging, gear processing, sheet metal stamping, riveting, heat treatment and mechanical processing. In recent years, the Germany CW1000 machining center, CNC four axis, five axis linkage machining center, CNC punch, large CNC hobbing gear grinding machine, large CNC floor boring and milling machine, Vacuum electron beam welding, CNC welding robot and 80 roll machine and other advanced processing equipment.



Drums information

the drum's outer diameter LBS sleeves diameter
width between the flanges 320mm 550mm or as your requirement
the rotation direction left or right
wire rope diameter and structure 22mm 33mm or any others
the material Q345B or high strength steel
the surface hardness as your requirements
